BMW M5 (E39)Photography coming soon
Widely regarded as the greatest sport sedan ever made. NA V8, manual gearbox, perfect balance in an understated suit.
History
The E39 M5 perfected the super sedan formula. Its S62 V8 was derived from the McLaren F1 engine program, individual throttle bodies giving it unforgettable response. Unlike the V10 E60, the E39 was discreet.
Production & Heritage
Production Total20,482
DesignerBMW M GmbH
Production Period1998–2003
Estimated Value$40K–$75K
Value estimates are editorial assessments based on recent auction results and market trends.
Technical Specifications
Engine4.9L V8 (S62B50)
Power400 hp @ 6,600 rpm
Torque500 Nm
0–60 mph4.8 sec
Top Speed250 km/h (Electronically limited)
Transmission6-speed manual (Getrag Type D)
DrivetrainRWD
Weight1,795 kg
Drag CoefficientCd 0.31
BodySteel unibody
Engine Details
Engine CodeS62B50
Displacement4.9L (4,941 cc)
Bore x Stroke94 x 89 mm
Compression11.0:1
Valves4 per cylinder (32 total)
Fuel SystemBosch MSS 52, individual throttle bodies
Performance
0–100 km/h4.8 sec
0–60 mph4.8 sec
Top Speed250 km/h (Electronically limited)
Weight-to-Power4.5 kg/hp
Dimensions
Length4,781 mm
Width1,800 mm
Height1,437 mm
Wheelbase2,830 mm
Chassis & Suspension
Front SuspensionDouble-pivot MacPherson strut, coil springs, anti-roll bar
Rear SuspensionMulti-link integral, coil springs, anti-roll bar
Front BrakesVentilated cross-drilled disc 345mm
Rear BrakesVentilated disc 328mm
SteeringRecirculating ball, speed-sensitive power-assist (Servotronic)
Tires (Front)245/40 ZR18
Tires (Rear)275/35 ZR18
Capacity
Fuel Tank70 L
Doors4
Seats5
Source: auto-data.net, BMW Group Archive
